4-Color 45pcs/Min CNC Automatic Screen Printing Machine For Tube And Bottle
उत्पाद विवरण:
| उत्पत्ति के प्लेस: | डोंगगुआन चाइना |
| ब्रांड नाम: | SENNY |
| प्रमाणन: | CE SGS |
| मॉडल संख्या: | एसआरएस1249 |
भुगतान & नौवहन नियमों:
| न्यूनतम आदेश मात्रा: | 1PC |
|---|---|
| मूल्य: | negotiable |
| पैकेजिंग विवरण: | प्लाईवुड पैकेज |
| प्रसव के समय: | 45 दिन |
| भुगतान शर्तें: | टी/टी |
| आपूर्ति की क्षमता: | 10 पीसी/महीना |
|
विस्तार जानकारी |
|||
| ऑटो ग्रेड: | पूरी तरह से स्वचालित | प्लेट प्रकार: | स्क्रीन प्रिंटर |
|---|---|---|---|
| बिक्री के बाद सेवाएं: | वीडियो या ऑन-लाइन | मुद्रित रंग: | 4 |
| प्रमुखता से दिखाना: | लाभ: यह चार रंगों में प्रिंट कर सकता है और विभिन्न आकारों के साथ उत्पादों को समायोजित कर सकता है, जै | ||
| प्रमुखता देना: | 4-color automatic screen printing machine,CNC screen printing machine for tubes,45pcs/min bottle screen printing machine |
||
उत्पाद विवरण
Machine Feature
- This machine is capable of performing screen-printing with multi-color UV inks, hot stamping, and other decorative processes on a variety of products. These include bottles, jars, caps, and items with irregular shapes, which can be made from materials such as plastic, metal, glass, and more.
- With an integrated turntable design, the machine accomplishes all printing tasks using the same set of fixtures. It boasts an impressive printing accuracy of up to ±0.1mm and ensures that products remain free from scratches during the process.
- Powered by a digitally controlled servo motor, the machine allows for 360-degree printing on products. In line with Industry 4.0 standards, it is also equipped with remote management and service functionalities.
Optional Configuration
- A function for loading and unloading products in a horizontal position.
- A function for examining the quality of finished products.
- A function for visual alignment of bottle bodies.
- An LED-UV curing system.
- A plasma surface treatment function.
- A function for visual alignment of bottle bottoms.
Technical Parameters
| Machine Model | SRS1249 |
| Printing Color | 4 |
| printing Speed | Up to 45 pcs/min |
| Diameter at 360 Degree | 13-600mm |
| Container Height | 20-200mm |
| Max.Printing Length | 200mm |
| Max.Printing Height | 160mm |
